Meiji Techno The HD1000-LITE 5MP CMOS Microscope Camera with HDMI and USB 2.0 w/ Free Shipping and Handling — 2 models

The Meiji Techno The HD1000-LITE 5MP CMOS Microscope Camera with HDMI and USB 2.0 is here at Opticsforyou.com and as usual we offer competitive prices Up to 15% Off!

Purchase your new Meiji Techno The HD1000-LITE 5MP CMOS Microscope Camera with HDMI and USB 2.0 from Opticsforyou.com today and you will appreciate the easy checkout process, fantastic customer service, Free Shipping policy and information on easily tracking your order.

The HD1000-LITE is Meiji Techno Americas Affordable HDMI /USB2.0 camera technology from Meiji Techno! It is the most economical HDMI & USB 2.0 camera in the market. You can easily operate the HD1000-LITE camera by directly connecting it to a monitor with a HDMI port without a PC and directly save images into an on-board SD-4G card on the camera, or connect the camera directly to your PC as it has a standard USB 2.0 interface to utilize the full annotation/software function The camera quickly reacts to lighting changes in any life science, clinical or material applications. With video output via HDMI connector, the setting menu allows easy access to feature settings. NOTE: 5MP Still Capture resolution 2592 x 1944 1920 x 1080- 15fps (frame per second) /1080P HDMI via HDMI 1920 x 1080 -15fps/1080p by USB 2.0) via USB 2.0

The HD-1000-LITE makes any microscope a full service digital microscope system. If you are predominatly looking at still shots and live video of your sample and a fast frame rate camera is not necessary for your application, the HD-1000-LITE is the perfect addition to your microscope trinocular port. Equipped with a 0.3 CMOS chip this camera requires a 0.3 C"mount adapter to give the user close to a 1:1 ratio to what you see in the eyepiece will be close to what you see through the monitor.

This HDMI/USB2.0 camera can be mounted directly to a PC via USB 2.0 or directly to a HDMI port on the HDMI tv or monitor, without having to attach it to a PC. This incorporate observation, image capture of still and live video and measurement capabilities while providing an on screen interface for viewing real time live images. Perform real time measurement on the PC when connected via USB 2.0. The HD-1000-LITE can provide more real time detail and are easier to navigate allowing the engineer or scientist to document images and make cost effective decisions in record time. You may also add a 11.8'' HDMI monitor in front of this camera by simply ordering the HD Monitor model, which includes the adapters for easy mounting. Easily save images on the SD card provided.

Specifications for Meiji Techno The HD1000-LITE 5MP CMOS Microscope Camera with HDMI and USB 2.0:

Features of Meiji Techno The HD1000-LITE 5MP CMOS Microscope Camera with HDMI and USB 2.0

• HDMI scientific imaging solution with a 1/2.5 inch sensor size by Micron MT9p001
• 2.2 x 2.2 Pixel size (um) color camera
• 5.0 MP effective pixel and a max resolution of 2592 x 1944
• PC Compatible
• Scan mode is progressive with a rolling shutter
• Interface 1 is HDMI
• Interface 2 is USB 2.0
• Frame rate is 15 fps (frame per second) /1080P HDMI
• 15fps (frame per second) /1080p by USB 2.0, frame rate streaming direct to monito
• Color Depth is 24 Bit
• A/D 8bi
• Exposure control is Manual /Auto
• Integration time is 1ms-10s
• White balance is Manual/Auto
• Responsivity 1.4V/ lux-sec
• Dynamic range is 70.1dB
• SNR is 38.1dB
• Optical Port : Standard Female C mount thread
• Capture : H4SD card(4G) Included
• Built in Software: Cloud 1.0 version
• Compatible OS :XP, Win 7/8, 32/64bit, MAC 0SX

Package Contents:

• Meiji Techno The HD1000-LITE 5MP CMOS Microscope Camera with HDMI and USB 2.0
