Meade LX600 ACF 12-inch f/8 Telescope w/ StarLock Star Tracking has been discontinued by Meade and is no longer available. Our product experts have helped us select these available replacements below.You can also explore other items in the Telescopes yourself to try and find the perfect replacement for you!
The Meade LX600 ACF 12-inch f/8 Telescope w/ StarLock Star Tracking is here at Opticsforyou.com and as usual we offer unbelievable prices and discounts !![]()
Purchase your new Meade LX600 ACF 12-inch f/8 Telescope w/ StarLock Star Tracking from Opticsforyou.com today and you will appreciate the easy checkout process, fantastic customer service, Free Shipping policy and information on easily tracking your order.
The Meade 12" LX600 Advanced Coma-Free f/8 Telescope is serious high-tech scope made for astrophotography and serious observation. This simple-to-operate, portable fork-mounted telescope makes taking great astrophotos as easy as focusing your camera and opening the shutter. The Meade LX600 12inch ACF Telescope builds on two standard-setting lines, with the venerable and standard-setting performance of the LX200, combined with the f/8 ACF optical system from the LX800 series, including the patent-pending internal Craford-style zero shift focuser. Add the Meade StarLock system full time automatic auto-guiding, ultra-high precision pointing, and LightSwitch style automatic alignments, and you have top-of-the-line portable telescope that will keep you locked on target whether you're viewing or photographing. The Meade LX600 12" Telescope offers a complete astrophotographic package, ready for field portable equatorial alignment, full time guiding, and imaging at f/8.
The Meade LX600 ACF 12 Telescope is a sophisticated instrument for the advanced astronomer, with a range of integrated features and technology that cannot be matched by any other manufacturer and cannot be duplicated by just attaching a set of add-ons to another telescope. Major features included with the Meade 12" LX600-ACF Astrophotography Telescope include:
The Meade 12" LX600 Telescope has 12" diameter f/8 ACF optics (focal length 2032mm) and Ultra-High Transmission Coatings (UHTC) for maximum image brightness and contrast. The redesigned mirror mounting system achieves zero image shift eliminating the need for a mirror lock and includes an internal Crayford style focuser with two speed, 7:1 reduction control that allows for quick and easy adjustments.
The no-compromise Meade LX-600 dual fork mount features 5.75" main gear and pointing accuracy of one arcminute or better in High Precision Mode. This rock solid platform is sure to exceed the need for the most demanding applications. The fully height adjustable Meade Giant Field Tripod features massive 3" diameter legs, making it a research grade foundation for the Meade LX600 12" Astrophotography Telescope.
| Clear Aperture: | 12" (305mm) | |
| Optical Design: | Advanced Coma Free (ACF) | |
| Focal Length: | 2,438mm | |
| Focal Ratio: | f/8 | |
| Telescope Mounting: | Heavy-duty fork type; double-tine | |
| Optical Coatings: | Ultra-High Transmission Coatings (UHTC) | |
| Resolving Power (Dawes Limit): | 0.38 arcseconds | |
| AutoStar Controller: | Autostar II | |
| Object Database: | 145,000 objects | |
| Viewfinder: | 8x50mm with cross-hair reticle | |
| Eyepiece: | 26mm Series 4000 Super Plossl | |
| Diagonal: | 1.25" diagonal prism | |
| Optimal back focus distance at f/5: | 3.5 inches | |
| Focus System: | Internal Crayford-style, zero image-shift primary mirror focus with dual speed 7 | |
| Slow Motion Controls: | Mechanical & electronic | |
| Slew Speeds: | RA and Dec | |
| Tracking Rates: | Sidereal, lunar, or custom-selected from 2000 incremental rates | |
| Control Panel: | 12v DC in, 12v DC out, Power, Focuser, Reticle, Handbox port, 1 computer connection port (RS232), 1 StarLock port, 1 Aux guide port | |
| Tripod: | Giant Field Tripod | |
| Batteries (User-Supplied): | 8 x C cells | |
| Battery Life (Typical): | 20 hrs. | |
| Power: | 12V DC | |
| Additional Features | ||
|---|---|---|
| GPS Receiver: | Included | |
| True Level & North Sensors (LNT): | Included | |
| Time Chip: | Included | |
| Smart Mount: | Yes | |
| Smart Drive: | Yes | |
| Mirror Lock: | Yes | |
| Oversized Primary Mirror: | Yes | |
| AutoStar Suite Planetarium Software: | Included | |
| StarLock | ||
| Wide Field Camera: | 25mm x 26mm f/1.04 optic with 1/2 inch format CMOS sensor gives field of 14.72 x 11.78 degrees. | |
| Narrow Field Camera: | 80mm x 400mm f/5 optic with 1/2 inch format Cmos sensor gives field | |
| : | of 57.2 x 45.8 arcminutes (2.68 arcseconds/pixel) | |
| High Precision Pointing: | +/- 1 arcminute | |
| High Precision Guiding: | Down to 1 arcsecond - depending on sky conditions. | |
| High Precision Alignment: | Semi-automatic drift align procedure for ulta-precise polar alignment | |
| StarLock Weight: | 6 lbs. (2.72 kg) | |
| Materials | ||
| Primary Mirror: | Low expansion borrosilicate glass | |
| Secondary Mirrors: | Individually figured with primary mirror for maximum correction. Low-expansion borosilicate glass | |
| Correcting Plate/Lens: | Aspheric high-spectral transmission Borofloat glass from Schott AG Germany | |
| Optical Tube: | Aluminum | |
| Weights and Dimensions | ||
| OTA and Mount net weight: | TBD | |
| Tripod Weight: | 50 lbs. | |
| Tripod Dimensions: | 40" to 50" variable | |
| Telescope Shipping Weight (approx.): | 179 lbs. | |
