Product Info for DNZ Products Savage-All Round Receiver
The DNZ Products Savage-All Round Receiver is here at Opticsforyou.com and as usual we offer unbelievable prices and discounts Up to 33% Off!
Purchase your new DNZ Products Savage-All Round Receiver from Opticsforyou.com today and you will appreciate the easy checkout process, fantastic customer service, Free Shipping policy and information on easily tracking your order.
Savage Round Receiver (2004 and newer) (Model 10,11,12,14,16,110,111,112,114,116,212,220):
With the new Nikon Prostaff P3 Shotgun scope you will need the HIGH 12200OS Mount. The focus ring is larger and you have to have a taller mount to keep it off the base.
Mount fits both left and right hand firearms.
Receiver is rounded on front and back of receiver where mounts attach.
MOA mounts are tapered down on front for long range shooting. Height will be about .03 lower on front ring than a standard mount. Base screws are 6-48 X 1/4 long and ring screws are 6-40 X 5/8 long. Both screws use a 7/64 Allen wrench.
Some of the Stealth models and .338 Lapua receivers have been modified at the factory and have larger base screws. The size of them is 8-40 and will use a 9/64 Allen wrench.
Short action - Outside to outside of rings is 4.36. Standard rings are .63 wide and have 2 ring screws per ring. Tactical rings are .80 wide and have 4 screws per ring. 4 Hole to hole spacing dimensions are .86, 3.94, .86. Height of mounts from top of receiver to centerline of scope tube is low .92, medium 1.05, and high 1.17.
Long action - Outside to outside of rings is 5.06. ( Offset ring mounts with OS for offset on end of part number are 4.42 outside to outside of rings for shorter tube scopes. Part 18200OS medium and 12200OS high ) Standard rings are .63 wide and have 2 ring screws per ring. Tactical rings are .80 wide and have 4 screws per ring. 4 Hole to hole spacing dimensions are .86, 4.63, .86. Height of mounts from top of receiver to centerline of scope tube is low .92, medium 1.05, and high 1.17.
Savage A17:
Mount fits both left and right hand firearms. Base screws are 6-48 X 1/4 long and ring screws are 6-40 X 5/8 long. Both screws use a 7/64 Allen wrench.
Outside to outside of rings is 4.14. Standard rings are .63 wide and have 2 screws per ring. 4 hole to hole spacing dimensions are .86, 3.19, .86. Height of mounts from top of receiver to centerline of scope tube is Low .92, medium 1.045, and high 1.17.
Specifications for DNZ Products Savage-All Round Receiver:
| Manufacturer: | DNZ Products |
| Fabric/Material: | 6061-T6 Aluminum |
| Gun Make: | Savage |
| Color: | Black |
| Hand: | Ambidextrous |
| Gun Type: | Rifle |
| Finish: | Matte |
Features of DNZ Products Savage-All Round Receiver
- Precision machined from a solid block of top-grade billet aluminum; Custom made to fit each type of firearm and align perfectly with your rifles receiver; No moving parts between the firearm and the scope; 67% lighter than comparable one-piece mounts with four times the threads and precision socket-head cap screws for absolute strength and security; Absorbs shock and withstands temperature extremes better than steel mounts at a fraction of the weight; made in specialized factories
Package Contents:
- DNZ Products Savage-All Round Receiver
