ATN Thor 3 Thermal Imaging Weapon Sight
Tap Tap to Zoom
Product No Longer Available
Unfortunately ATN Thor 3 Thermal Imaging Weapon Sight is not listed by OpticsForYou.
Product Info for ATN Thor 3 Thermal Imaging Weapon Sight
The ATN Thor 3 Thermal Imaging Weapon Sight is here at Opticsforyou.com and as usual we offer great deals !
Purchase your new ATN Thor 3 Thermal Imaging Weapon Sight from Opticsforyou.com today and you will appreciate the easy checkout process, fantastic customer service, Free Shipping policy and information on easily tracking your order.
ATN ThOR 3 Thermal Weapon Sight combines the ergonomic features of a handheld thermal device and the convenience of a weapon mount. The ATN ThOR Thermal Optical Rifle Scope are based upon a proven 320 x 240 microbolometer core, which is coupled with a high resolution OLED Microdisplay Assembly that provides exceptional resolution and clarity. Uncooled thermal imaging cuts through dust, smoke, fog, haze, and other battlefield obscurants. The ATN THOR 3 Thermal Rifle Scope cannot be detected as it emits no visible light or RF energy, and operates without the use of illuminators or IR lights.
The ATN ThOR Thermal Weapon Sights are the only thermal weapon sights with the proprietary ATN Two Color Manual Brightness control of the aiming reticle. This feature allows for a choice of color of the projected reticle depending on the operator's preference and tactical situation. The ATN ThOR Thermal Imaging Scope is built with a 3x optical magnification, providing increased resolution over digital zoom models. To achieve superior accuracy and precision the ATN ThOR Scopes utilize a rear projected optical precision windage and elevation system. Waterproof and he ATN ThOR Thermal Scope is an ideal product for force protection, border patrol officers, police SWAT and special operations forces, providing them with a thermal imaging scope that lets them be successful in all field conditions both day and night.
Available models of the ATN Thor Thermal Rifle Scope include:
- TIWSTHOR3B: Black and white / grayscale display
- TIWSTHOR3C: Color display - cooler temperatures are displayed in darker, "cooler" colors (blues, purples). Higher temps appear as "warm" colors (reds, yellows, oranges).
A full line of genuine ATN Thermal Imaging scopes is on sale and available from our store. All Thermal Imaging devices by ATN from our online store come with the Full Manufacturer's Warranty.
Specifications for ATN THOR Thermal Imaging Weapon Sight:
| Sensor (microbolometer): | 320 x 240 |
| Type Uncooled: | 30 hz |
| Image Size (output resolution): | NTSC |
| Video output: | NTSC |
| Display, Color OLED: | 852 x 600 |
| Thermal Sensitivity: | mK50 |
| Spectral Response, μm: | 7 - 14 |
| Focal length of the lens: | 75 |
| Field of View (H x V), degree: | 8 x6 |
| Angular resolution, mrad: | 0.6 |
| Diopter: | ± 5 |
| Eye Relief, mm: | 45 |
| Magnification: | 3x (digital 6x) |
| Digital Zoom: | 2 |
| Focus: | Manual |
| Focusing range, m: | 5 to infinity |
| Diameter of exit pupil, mm: | 10 |
| Distance of the human detection, m: | 900 |
| Distance of the human recognition, m: | 450 |
| Reticle: | Crosshair, 2 colors |
| Windage and Elevation Adjustment: | ± 1° |
| Step of Windage and Elevation Adjustment: | 3/4 MOA |
| Brightness adjustment: | Manual |
| Sharpness adjustment: | Automatic |
| Polarity control (only in Black and White mode): | White hot / Black hot |
| Start up time, seconds: | <4 |
| Storage temperature: | -50°C to +90°C |
| Operating temperature: | -20°C to +60°C |
| Waterproof: | 10 m for 1h |
| Battery type: | 4(CR123A) x 3V |
| Battery Life: | 6 hrs |
| Weight, g (without bracket, with battery): | 940 |
| Dimensions: | :215 x 77 x 83 mm / 8.5" x 3.0" x 3.3" |
| Mounting bracket: | Picatinny Quick Release |
| External control: | No |
| External power: | 9 - 12 V DC |
Features of ATN Thor Three Thermal Imaging Weapon Sight:
- High resolution OLED Microdisplay digital thermal imaging
- Amorphous Silicon detector with 320 x 240 resolution
- Large high-performance lens system with 3x optical magnification
- Two Color, manual brightness controlled reticle
- Precision internal windage and elevation adjustment
- Digital operating control with direct button access
- Manual image refresh switch
- Digital zoom for surveillance purposes
- In and output video
- Rapid start-up in 3 seconds
- Up to 6 hours operation with four lithium batteries
- MIL-STD-1913 (Picatinny Rail) Quick release Mount
- Compact, light weight, convenient
- Rugged, full-metal, extra durable body
- Hand-held usage
Package Contents:
- ATN Thor 3 Thermal Imaging Weapon Sight TIWSTHOR 3x
- Lens Tissue
- Video Cable
- Instruction Manual
- 4 batteries CR123A type
- Tripod Adapter
